Sinbosen K-800 1U class D 2 channel professional digital power amplifier
DIGITAL AMPLIFIER

Sinbosen K-800 class d amplifier home audio best sounding class d amplifier

Model: K-800
Channel: 2 channel power amplifier
Output Power:
8Ω Stereo Power (RMS): 800W X 2CH
4Ω Stereo Power (RMS): 1,200W X 2CH
Class: D
Certification: CE, ROHS, TUV
Warranty: 3 Years
Special service: OEM
Description

Sinbosen K&AD-Series Amplifier
  k-1200 k-1000 k-800
8 ohm Stereo Power  (RMS) 1200WX2 1000WX2 800WX2
4 ohm Stereo Power  (RMS) 1850WX2 1500WX2 1200WX2
2 ohm Stereo Power  (RMS) 2300WX2 2000WX2 1600WX2
Power Type Switching Power Supply
Amplifier Type Composite Feedback Control Class D
Height 1U
Rate Output Voltage(THD+N<1%,1khz) 100V RMS
Power Specification AC 90V-240V(+15%)45-65Hz
Input Connectors  XLR(Female)
Output Connectors  Speakon Block
Noise insulation factor(1KHz) >250
Input impedance 20K ohms Balance,10K ohms Unbalanced
Input sensitivity(1KHz) 0.775V/26/32dB
Input impedance 20K (balance)/10k (imbalance)
Cooling Type Stepless Speed Regulation Cooling Fan,Air Flow From Front To Bcak
Amplifier And Load Protection Short Circuit,Thermal,Over current,DC voltage,Ultra High freuency protection

K-800 digital amplifiers are 2-channels 1U digital amplifiers and light weight.A perfect Sound reinforcement used in multiple ranges of home and paging applications such as home, theater, office, malls.






►2 Channel Class TD Digital power amplifier
►Mini 1U size,convenient for Touring Applications
►2 x 1,200 Watts into 4 Ohms, 2 x 800 Watts into 8 Ohms
►Precise and Reasonable circuit structure
►Bring supper reliable sound
►Bridge-mode operation for Touring Applications
►Use NTC boot soft start.
►With PFC automatic voltage regulator circuit.
►Each channel has independent overpressure and overheating.
►load short-circuit protection.
►There is an automatic limiting function to prevent damage to the sounder.
►Balanced input XLR stereo (two channels), stereo and bridge modes of operation.
